About the Detailed Engineering Drawings, Codes & Standards: P&ID Reading, Interpretation & Developing Course

Time Training Center's 5-day/30-hour Detailed Engineering Drawings, Codes & Standards course equips professionals to accurately interpret and develop engineering drawings, with a focus on P&IDs. ​This course is suitable for anyone involved in the design, construction, or operation of industrial plants and systems.​

The program offers a comprehensive understanding of international codes and standards. These include ASME, API, and ISO, which are vital for ensuring compliance and enhancing the integrity of engineering documentation. You gain in-depth knowledge on interpreting P&IDs, understanding their role in process control, and identifying and resolving design discrepancies.

Through a blend of theoretical instruction, practical exercises, and real-world case studies, you will enhance your skills. You will significantly improve your ability to contribute to project planning, operational efficiency, and troubleshooting in industrial environments.

Detailed Engineering Drawings, Codes & Standards: P&ID Reading, Interpretation & Developing Course Objectives

​By the end of this Detailed Engineering Drawings, Codes & Standards: P&ID Reading, Interpretation & Developing training course, participants will be able to:​

• Develop a comprehensive understanding of the structure and content of P&IDs, including symbols, annotations, and functional representations of process equipment and control systems.
• Gain proficiency in reading, interpreting, and analysing P&IDs to identify key process flow paths, equipment configurations, control loops, and safety interlocks.
• Learn how to integrate engineering codes and standards, including ASME, API, ANSI, and ISO, into the development and interpretation of engineering drawings to ensure compliance with industry best practices.
• Acquire the ability to identify and troubleshoot discrepancies or errors in P&IDs and other related engineering documentation.
• Learn the practical application of engineering drawings throughout the lifecycle of a project, from design to commissioning, operations, and maintenance.
• Understand the methodologies for updating, revising, and optimising P&IDs to reflect operational changes, process improvements, or troubleshooting results.

Training Methodology

We employ a comprehensive and applied learning strategy, integrating theory with real-world implementation:

• 30% Conceptual Learning: Expert-led sessions on catalytic theory and engineering principles
• 20% Interactive Workshops: Group exercises, presentations, and technical discussion forums
• 30% Case-Based Learning: Industry-specific examples and troubleshooting scenarios
• 20% Technology Integration: Digital tools, simulations, and catalyst modelling applications

Note: Instructors may adjust the training approach to fit technical requirements or participant engagement levels.

Course Instructor:

Our courses are delivered by highly qualified instructors with extensive experience in both industry and academia. With decades of hands-on expertise across a wide range of technical disciplines, our instructors are dedicated to providing high-quality, impactful training that equips participants with practical knowledge and skills they can immediately apply. Full instructor profiles are available upon request.

Course Fees

The course fee includes the following:

• Course Materials: Comprehensive participant materials, including lecture notes, slides, and case study documents. (Tablet or IPAD)
• Coffee/Tea: Provided on arrival and during morning and afternoon breaks to keep participants refreshed.
• Buffet Lunch: Served daily to ensure participants have an opportunity to network and recharge during lunch breaks.

Who Should Attend Our Detailed Engineering Drawings, Codes & Standards Course?

This training course is highly beneficial for professionals involved in the development, reading, and interpretation of engineering drawings, including:

• Process and design engineers
• Project managers and supervisors
• Maintenance and operations personnel
• Professionals involved in process design and documentation
• Engineering consultants and technical specialists working with P&IDs and process systems.

Detailed Engineering Drawings, Codes & Standards: P&ID Reading, Interpretation & Developing Course Outline

Module 1: Fundamentals of Engineering Drawings and P&IDs

• Pre-test assessment of existing knowledge
• Introduction to engineering drawings and their role in industrial design, construction, and operation
• Detailed exploration of P&ID components: Equipment, instrumentation, piping, and control systems
• Understanding the purpose and function of various types of engineering drawings (P&IDs, PFDs, Isometrics, etc.)
• Overview of the graphical symbols and conventions used in P&ID design
• Review of the various standards and guidelines governing the development of P&IDs, including ISA-5.1, ANSI, and others

Module 2: P&ID Interpretation Techniques

• In-depth techniques for reading and analysing the layout and design details in P&IDs
• Identifying and understanding the representation of process flow paths, equipment, instrumentation, and control loops in P&IDs
• Understanding the role of safety systems, including emergency shutdown (ESD) systems, alarms, and interlocks
• Techniques for extracting vital operational information from P&IDs to support decision-making in system design, operations, and troubleshooting
• Identifying key equipment symbols, valve types, pressure and temperature instrumentation, and control loops in the P&ID context

Module 3: Codes and Standards in Engineering Drawings

• Overview of international codes and standards impacting engineering drawings: ASME, API, ANSI, ISO
• Understanding compliance requirements for mechanical and process systems, including safety, quality, and operational standards
• Integrating industry standards into P&ID development to ensure conformity with regulatory requirements
• Detailed discussion on the selection of appropriate symbols and notations based on standardisation practices in process systems
• Best practices for aligning P&ID content with industry-recognised safety and operational codes

Module 4: Practical Application and Troubleshooting

• Case study analysis of common discrepancies and errors in P&IDs
• Practical approaches to identifying and resolving design inconsistencies and inaccuracies
• Reviewing examples of P&ID updates and revisions in response to operational feedback or process modifications
• Best practices for implementing changes in engineering documentation while maintaining consistency and clarity across all project documents
• Exploring common pitfalls in P&ID interpretation and troubleshooting through hands-on problem-solving sessions

Module 5: Advanced Applications and Industry Trends

• Overview of digital tools and software for engineering drawings and P&ID development (e.g., AutoCAD, P&ID design software)
• Integrating collaborative workflows for multidisciplinary teams in the development and review of P&IDs
• The role of data integration in modern engineering documentation practices and digital transformation
• Practical exercises in creating and interpreting advanced P&IDs, incorporating process changes, new equipment, and updated control systems
• Examining emerging trends in P&ID design and interpretation in response to evolving industry technologies and methodologies

Module 6: Capstone and Assessment

• Review of Core Topics and Key Learnings
• Final Group Discussion and Q&A
• Post-Test Evaluation
• Certificate Presentation

Course Completion Certificate

Upon completing your course at Time Training Center, you will be awarded an official Course Completion Certificate, recognising your achievement and the skills you've gained. This certificate validates your expertise and reflects the high standards of training you've undergone.
